Adet bazlı fiyat
- 1+ adet$20.43
- 10+ adet$19.27
- 100+ adet$18.18
- 500+ adet$17.15
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Body Finish
- White Bronze
- Yayın Yılı
- 2014
- Fabrika Tedarik Süresi
- 13 Weeks
- Convert From Adapter End
- QMA Plug, Male Pin
- Conversion Type
- Between Series
- Frequencymax
- 18GHz
- Contact Finish Mating
- NOT SPECIFIED
- Fastening Type
- Snap-On, Threaded
- Iec Conformance
- YES
- Filter Feature
- NO
- Adapter Series
- SMA to QMA
- Convert To Adapter End
- SMA Jack, Female Socket
- Operating Frequency Max
- 18GHz
- Adapter Type
- Plug to Jack
- RoHS Durumu
- RoHS Compliant
- Style
- Straight
- Empedans
- 50Ohm
- Parça Durumu
- Active
- Center Gender
- Female to Male
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Din Conformance
- NO
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Panel Mount
- NO
- Insertion Loss
- 0.21 dB
- Mil Conformance
- NO
- Mating Cycles
- 100
- Center Contact Plating
- Gold
- Additional Feature
- STANDARD: IEC 60169, VSWR MAX AT 6 GHZ
- Center Contact Material
- Beryllium Copper
- Montaj Tipi
- Free Hanging (In-Line)
- ECCN Kodu
- EAR99
- HTS Kodu
- 8536.69.80.00
- Contact Gender
- MALE-FEMALE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Body Material
- Brass; Bronze
- Çalışma Sıcaklığı
- -40°C~85°C
- Option
- GENERAL PURPOSE
- Vswr
- 1.12
