Adet bazlı fiyat
- 1+ adet$25.48
- 10+ adet$24.04
- 100+ adet$22.68
- 500+ adet$21.39
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Convert From Adapter End
- QMA Jack, Female Socket
- Adapter Series
- SMA to QMA
- Additional Feature
- STANDARD: IEC 60169, VSWR MAX AT 6 GHZ
- Parça Durumu
- Active
- HTS Kodu
- 8536.69.80.00
- Insertion Loss
- 0.21 dB
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Adapter Type
- Jack to Jack
- Center Contact Plating
- Gold
- Conversion Type
- Between Series
- ECCN Kodu
- EAR99
- Operating Frequency Max
- 18GHz
- Çalışma Sıcaklığı
- -40°C~85°C
- Fastening Type
- Snap-On, Threaded
- Body Finish
- White Bronze
- Montaj Tipi
- Free Hanging (In-Line)
- Center Gender
- Female to Female
- Yayın Yılı
- 2014
- Mating Cycles
- 100
- Iec Conformance
- YES
- Fabrika Tedarik Süresi
- 13 Weeks
- Convert To Adapter End
- SMA Jack, Female Socket
- Din Conformance
- NO
- Mil Conformance
- NO
- Contact Gender
- FEMALE-FEMALE
- Contact Finish Mating
- NOT SPECIFIED
- RoHS Durumu
- RoHS Compliant
- Center Contact Material
- Beryllium Copper
- Style
- Straight
- Vswr
- 1.12
- Filter Feature
- NO
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Option
- GENERAL PURPOSE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Panel Mount
- NO
- Frequencymax
- 18GHz
- Empedans
- 50Ohm
- Body Material
- Brass
