Adet bazlı fiyat
- 1+ adet$5.76
- 10+ adet$5.43
- 100+ adet$5.12
- 500+ adet$4.83
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- ECCN Kodu
- EAR99
- Reliability
- COMMERCIAL
- Panel Mount
- NO
- Number Of Ports
- 1
- Contact Style
- COAX
- Additional Feature
- STANDARD: MIL-STD-202; CAPTIVE CENTER CONTACT
- Total Number Of Contacts
- 1
- Mating Cycles
- 500
- Connector Style
- SMP
- Body Material
- Brass
- Frequencymax
- 26.5GHz
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Iec Conformance
- NO
- Center Contact Plating
- Gold
- Connector Type
- Plug, Male Pin
- Operating Frequency Max
- 40GHz
- JESD-609 Kodu
- e4
- Polarization Key
- POLARIZED HOUSING
- Dielectric Withstanding Voltage
- 700VAC V
- Empedans
- 50Ohm
- Filter Feature
- NO
- Fabrika Tedarik Süresi
- 13 Weeks
- Contact Resistance
- 6mOhm
- Özellikler
- Limited Detent
- Mil Conformance
- YES
- Din Conformance
- NO
- Çalışma Sıcaklığı
- -65°C~155°C
- Kurşunsuz Kodu
- yes
- Insertion Forcemax
- 44.9248 N
- Withdrawl Forcemin
- 9.7856 N
- Insertion Loss
- 0.63 dB
- Fastening Type
- Snap-On
- Option
- GENERAL PURPOSE
- Mounting Option1
- LOCKING
- Dielectric Material
- Liquid Crystal Polymer (LCP)
- RoHS Durumu
- RoHS Compliant
- Montaj Tipi
- Surface Mount
- Ambalaj
- Tape & Reel (TR)
- Nominal Gerilim
- 335V
- Insulation Materials
- LCP/PEEK/PTFE
