Adet bazlı fiyat
- 1+ adet$9.65
- 10+ adet$9.10
- 100+ adet$8.59
- 500+ adet$8.10
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Din Conformance
- NO
- Çalışma Sıcaklığı
- -65°C~155°C
- Mil Conformance
- YES
- Özellikler
- Limited Detent
- Contact Resistance
- 6mOhm
- Contact Finish Mating
- NOT SPECIFIED
- Fabrika Tedarik Süresi
- 13 Weeks
- Yayın Yılı
- 2014
- Filter Feature
- NO
- Empedans
- 50Ohm
- Parça Durumu
- Active
- Contact Termination
- Solder
- Nominal Gerilim
- 335V
- Insulation Materials
- LCP/PEEK/PTFE
- Vswr
- 1.5
- Montaj Tipi
- Through Hole
- RoHS Durumu
- RoHS Compliant
- Dielectric Material
- Polyetheretherketone (PEEK)
- Mounting Option1
- LOCKING
- Insertion Loss
- 0.63 dB
- Fastening Type
- Snap-On
- Option
- GENERAL PURPOSE
- Frequencymax
- 26.5GHz
- Body Material
- Brass
- Connector Style
- SMP
- Mating Cycles
- 500
- Total Number Of Contacts
- 1
- Additional Feature
- STANDARD: MIL-STD-202; CAPTIVE CENTER CONTACT
- Contact Style
- RND PIN-SKT
- Number Of Ports
- 1
- Reliability
- COMMERCIAL
- Panel Mount
- NO
- ECCN Kodu
- EAR99
- Contact Materials
- NOT SPECIFIED
- Operating Frequency Max
- 40GHz
- Connector Type
- Plug, Male Pin
- Center Contact Plating
- Gold
- Iec Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
