Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Body Material
- Beryllium Copper
- Mil Conformance
- NO
- Style
- Straight
- Center Gender
- Female to Female
- Montaj Tipi
- Free Hanging (In-Line)
- Reliability
- COMMERCIAL
- Fastening Type
- Snap-On, Snap-On
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Fabrika Tedarik Süresi
- 11 Weeks
- Frequencymax
- 26.5GHz
- Din Conformance
- NO
- Convert To Adapter End
- SMP Jack, Female Socket
- Empedans
- 50Ohm
- Adapter Series
- SMP to SMP
- Iec Conformance
- NO
- Insertion Loss
- 0.21 dB
- RoHS Durumu
- RoHS Compliant
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Option
- GENERAL PURPOSE
- Panel Mount
- NO
- Additional Feature
- INSERTION LOSS AND VSWR MAX AT: 18 GHZ
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Center Contact Plating
- Gold
- Çalışma Sıcaklığı
- -65°C~155°C
- Center Contact Material
- Beryllium Copper
- Vswr
- 1.58
- Convert From Adapter End
- SMP Jack, Female Socket
- Operating Frequency Max
- 26.5GHz
- Contact Finish Mating
- NOT SPECIFIED
- Filter Feature
- NO
- Yayın Yılı
- 2007
- Parça Durumu
- Active
- Adapter Type
- Jack to Jack
- Conversion Type
- Same Series
