Adet bazlı fiyat
- 1+ adet$12.25
- 10+ adet$11.56
- 100+ adet$10.90
- 500+ adet$10.29
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Panel Mount
- NO
- Additional Feature
- STANDARD: MIL-STD-202; CAPTIVE CENTER CONTACT
- Option
- GENERAL PURPOSE
- Connector Style
- SMP
- Cable Group
- RG-316
- Çalışma Sıcaklığı
- -65°C~155°C
- Vswr
- 1.5
- Center Contact Material
- Beryllium Copper
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Center Contact Plating
- Gold
- Total Number Of Contacts
- 1
- Insulation Materials
- LCP/PEEK/PTFE
- RoHS Durumu
- RoHS Compliant
- Insertion Loss
- 0.63 dB
- Filter Feature
- NO
- Nominal Gerilim
- 335V
- Insulation Resistance
- 5000000000Ohm
- Connector Type
- Jack, Female Socket
- Parça Durumu
- Active
- Operating Frequency Max
- 40GHz
- JESD-609 Kodu
- e4
- Reliability
- COMMERCIAL
- Fastening Type
- Snap-On
- Contact Style
- COAX
- Montaj Tipi
- Free Hanging (In-Line)
- Body Material
- Beryllium Copper
- Contact Resistance
- 6mOhm
- Number Of Ports
- 1
- Kurşunsuz Kodu
- yes
- Mil Conformance
- YES
- Empedans
- 50Ohm
- Iec Conformance
- NO
- Contact Termination
- Crimp
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Frequencymax
- 26.5GHz
- ECCN Kodu
- EAR99
- Din Conformance
- NO
- Mounting Option1
- LOCKING
- Body Depth
- 0.65 inch
- Fabrika Tedarik Süresi
- 11 Weeks
