Adet bazlı fiyat
- 1+ adet$10.82
- 10+ adet$10.21
- 100+ adet$9.63
- 500+ adet$9.08
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Frequencymax
- 65GHz
- Çalışma Sıcaklığı
- -55°C~155°C
- Vswr
- 2.1
- Center Contact Plating
- Gold
- Contact Finish Mating
- NOT SPECIFIED
- Connector Type
- Plug, Male Pin
- Reliability
- COMMERCIAL
- Contact Termination
- Solder
- Center Contact Material
- Beryllium Copper
- Dielectric Withstanding Voltage
- 450VAC V
- Yayın Yılı
- 2018
- Option
- GENERAL PURPOSE
- Connector Style
- SMP, Mini
- Fabrika Tedarik Süresi
- 13 Weeks
- Filter Feature
- NO
- Mating Cycles
- 100
- Insulation Resistance
- 5000000000Ohm
- Fastening Type
- Snap-On
- Nominal Gerilim
- 325V
- Iec Conformance
- NO
- Number Of Ports
- 1
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Empedans
- 50Ohm
- Mil Conformance
- NO
- Mounting Option1
- LOCKING
- Additional Feature
- INSERTION LOSS MAX AT: 26.5 GHZ
- Özellikler
- Smooth Bore
- Insertion Loss
- 0.26 dB
- ECCN Kodu
- EAR99
- Operating Frequency Max
- 65GHz
- Dielectric Material
- Polyetheretherketone (PEEK)
- Total Number Of Contacts
- 1
- Montaj Tipi
- Surface Mount
- Body Material
- Brass
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Style
- COAX
- Panel Mount
- NO
- Din Conformance
- NO
- Contact Resistance
- 6mOhm
