Adet bazlı fiyat
- 1+ adet$82.03
- 10+ adet$77.38
- 100+ adet$73.00
- 500+ adet$68.87
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Kurşunsuz Kodu
- yes
- Montaj Tipi
- Free Hanging (In-Line)
- Din Conformance
- NO
- Center Contact Plating
- Gold
- ECCN Kodu
- EAR99
- Çalışma Sıcaklığı
- -55°C~155°C
- Vswr
- 1.11
- Coupling Type
- SNAP-THREADED
- Center Gender
- Female to Female
- HTS Kodu
- 8536.69.80.00
- Operating Frequency Max
- 10GHz
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Convert From Adapter End
- PSMP Jack, Female Socket
- Center Contact Material
- Beryllium Copper
- Convert To Adapter End
- SMA Jack, Female Socket
- Body Finish
- Gold; Passivated
- Fabrika Tedarik Süresi
- 11 Weeks
- Conversion Type
- Between Series
- Adapter Series
- SMA to PSMP
- Parça Durumu
- Active
- Body Material
- Beryllium Copper; Stainless Steel
- Fastening Type
- Snap-On, Threaded
- JESD-609 Kodu
- e4
- Empedans
- 50Ohm
- Option
- GENERAL PURPOSE
- Yayın Yılı
- 2014
- Frequencymax
- 10GHz
- Insertion Loss
- 0.16 dB
- Panel Mount
- NO
- Iec Conformance
- NO
- Style
- Straight
- RoHS Durumu
- RoHS Compliant
- Adapter Type
- Jack to Jack
- Mil Conformance
- NO
- Filter Feature
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
