Adet bazlı fiyat
- 1+ adet$8.35
- 10+ adet$7.87
- 100+ adet$7.43
- 500+ adet$7.01
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fastening Type
- Snap-On, Snap-On
- JESD-609 Kodu
- e4
- Parça Durumu
- Active
- Body Material
- Beryllium Copper
- Panel Mount
- NO
- Yayın Yılı
- 2015
- Empedans
- 50Ohm
- Option
- GENERAL PURPOSE
- Insertion Loss
- 0.09 dB
- Frequencymax
- 10GHz
- RoHS Durumu
- RoHS Compliant
- Style
- Straight
- Adapter Type
- Jack to Jack
- Iec Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Filter Feature
- NO
- Mil Conformance
- NO
- ECCN Kodu
- EAR99
- Center Contact Plating
- Gold
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Din Conformance
- NO
- Montaj Tipi
- Free Hanging (In-Line)
- Kurşunsuz Kodu
- yes
- Çalışma Sıcaklığı
- -65°C~165°C
- Vswr
- 1.15
- Operating Frequency Max
- 10GHz
- Convert From Adapter End
- PSMP Jack, Female Socket
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Additional Feature
- VSWR MAX AT: 6 GHZ
- HTS Kodu
- 8536.69.80.00
- Center Gender
- Female to Female
- Coupling Type
- SNAP-SNAP
- Contact Gender
- FEMALE-FEMALE
- Conversion Type
- Same Series
- Fabrika Tedarik Süresi
- 11 Weeks
- Adapter Series
- PSMP to PSMP
- Center Contact Material
- Beryllium Copper
- Convert To Adapter End
- PSMP Jack, Female Socket
- Body Finish
- White Bronze
