Adet bazlı fiyat
- 1+ adet$307.15
- 10+ adet$289.77
- 100+ adet$273.37
- 500+ adet$257.89
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Coupling Type
- THREADED-THREADED
- Conversion Type
- Same Series
- Convert From Adapter End
- 2.4mm (APC-2.4, OS-50) Plug, Male Pin
- Vswr
- 1.33
- Empedans
- 50Ohm
- Style
- Straight
- JESD-609 Kodu
- e4
- Panel Mount
- NO
- Mil Conformance
- NO
- Option
- GENERAL PURPOSE
- Adapter Type
- Plug to Plug
- Additional Feature
- CAPTIVE CENTER CONTACT
- Dielectric Material
- Polyetheretherketone (PEEK)
- Body Material
- Stainless Steel
- Parça Durumu
- Active
- Filter Feature
- NO
- Seri
- RPC
- Montaj Tipi
- Free Hanging (In-Line)
- Operating Frequency Max
- 50GHz
- Center Contact Material
- Beryllium Copper
- Çalışma Sıcaklığı
- -40°C~85°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Iec Conformance
- NO
- Center Gender
- Male to Male
- Convert To Adapter End
- 2.4mm (APC-2.4, OS-50) Plug, Male Pin
- Frequencymax
- 50GHz
- Adapter Series
- RPC-2.40 to RPC-2.40
- RoHS Durumu
- RoHS Compliant
- Contact Gender
- MALE-MALE
- Fabrika Tedarik Süresi
- 13 Weeks
- Din Conformance
- NO
- Mating Cycles
- 500
- Fastening Type
- Threaded, Threaded
- Insertion Loss
- 2.5 dB
- Center Contact Plating
- Gold
- Yayın Yılı
- 2006
