Adet bazlı fiyat
- 1+ adet$365.86
- 10+ adet$345.15
- 100+ adet$325.61
- 500+ adet$307.18
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fastening Type
- Snap-On, Threaded
- Body Finish
- Gold; Passivated
- Insertion Loss
- 3.25 dB
- Din Conformance
- NO
- Yayın Yılı
- 2006
- Center Contact Plating
- Gold
- Center Gender
- Female to Male
- Montaj Tipi
- Free Hanging (In-Line)
- Seri
- RPC
- Operating Frequency Max
- 65GHz
- Çalışma Sıcaklığı
- -40°C~85°C
- Center Contact Material
- Beryllium Copper
- Iec Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 13 Weeks
- Contact Gender
- MALE-FEMALE
- Convert To Adapter End
- SMP Mini Jack, Female Socket
- Frequencymax
- 65GHz
- Adapter Series
- SMP, Mini to RPC-1.85
- RoHS Durumu
- RoHS Compliant
- Dielectric Material
- Polyetheretherketone (PEEK)
- Additional Feature
- CAPTIVE CENTER CONTACT
- Adapter Type
- Plug to Jack
- Parça Durumu
- Active
- Filter Feature
- NO
- Body Material
- Beryllium Copper; Stainless Steel
- Convert From Adapter End
- 1.85mm Plug, Male Pin
- Vswr
- 1.43
- Empedans
- 50Ohm
- Style
- Straight
- Coupling Type
- THREADED-THREADED
- Conversion Type
- Between Series
- JESD-609 Kodu
- e4
- Panel Mount
- NO
- Option
- GENERAL PURPOSE
- Mil Conformance
- NO
