Teknik Özellikler
- Dielectric Material
- Polyetheretherketone (PEEK); Polytetrafluoroethylene (PTFE)
- Contact Termination
- Solder
- Body Material
- Brass
- Özellikler
- Mounting Hardware
- Parça Durumu
- Active
- Empedans
- 50Ohm
- Shield Termination
- Screw
- Includes
- 3 pcs - 1 Connector, 2 Screws
- Number Of Ports
- 1
- Mating Cycles
- 500
- Fastening Type
- Threaded
- Mounting Option1
- LOCKING
- Insertion Loss
- 0.05 dB
- Center Contact Plating
- Gold
- Total Number Of Contacts
- 1
- Connector Type
- Jack, Female Socket
- Contact Resistance
- 4mOhm
- Yayın Yılı
- 2018
- Seri
- RPC
- Connector Style
- 1.85mm
- Montaj Tipi
- Board Edge, End Launch
- Operating Frequency Max
- 70GHz
- Center Contact Material
- Beryllium Copper
- Contact Style
- COAX
- Çalışma Sıcaklığı
- -55°C~125°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Frequencymax
- 70GHz
- Body Depth
- 0.606 inch
- Nominal Gerilim
- 150V
- RoHS Durumu
- RoHS Compliant
- Reliability
- COMMERCIAL
- Fabrika Tedarik Süresi
- 13 Weeks
