Teknik Özellikler
- Montaj Tipi
- Free Hanging (In-Line)
- Insulation Materials
- POLYETHERETHERKETONE/POLYSTYROL
- Vswr
- 1.2
- Contact Gender
- FEMALE-FEMALE
- Conversion Type
- Between Series
- Parça Durumu
- Active
- Operating Frequency Max
- 40GHz
- Body Material
- Beryllium Copper; Stainless Steel
- Center Gender
- Female to Female
- Frequencymax
- 40GHz
- Center Contact Material
- Beryllium Copper
- Style
- Straight
- Iec Conformance
- NO
- Center Contact Plating
- Gold
- Dielectric Material
- Polyetheretherketone (PEEK)
- Coupling Type
- SNAP-THREADED
- Seri
- RPC
- Insertion Loss
- 1.6 dB
- Adapter Type
- Jack to Jack
- Filter Feature
- NO
- Panel Mount
- NO
- Din Conformance
- NO
- Convert From Adapter End
- 2.92mm (OS-2.9) Jack, Female Socket
- Body Finish
- Gold; Passivated
- Convert To Adapter End
- SMP Jack, Female Socket
- RoHS Durumu
- RoHS Compliant
- Option
- GENERAL PURPOSE
- JESD-609 Kodu
- e4
- Additional Feature
- VSWR AT 12 GHZ: 1.05; VSWR AT 26.5 GHZ: 1.1
- Fabrika Tedarik Süresi
- 13 Weeks
- Yayın Yılı
- 2013
- Fastening Type
- Snap-On, Threaded
- Mil Conformance
- NO
- Empedans
- 50Ohm
- Adapter Series
- SMP to RPC-2.92
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
