Adet bazlı fiyat
- 1+ adet$668.68
- 10+ adet$630.83
- 100+ adet$595.12
- 500+ adet$561.44
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Frequency Range
- DC~40GHz
- Termination Type
- SOLDER/CONNECTOR
- Coilinput Supply Type
- DC
- Yayın Yılı
- 2008
- Rf Type
- General Purpose
- Empedans
- 50Ohm
- Circuit
- SPDT
- Coil Power
- 2240mW
- Electricallife
- 10000000 Cycle(s)
- Additional Feature
- SMA, BUILT-IN TTL DRIVER, SELF CUT OFF AND INDICATOR
- Coil Voltagedcmax
- 28V
- Relay Type
- RF COAXIAL RELAY
- Test Frequency
- 40GHz
- Physical Dimension
- 34mm x 12.8mm x 38mm
- ECCN Kodu
- EAR99
- Kılıf / Paket
- Module, SMA Connectors
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Relay Action
- LATCHED
- RoHS Durumu
- Non-RoHS Compliant
- Fabrika Tedarik Süresi
- 4 Weeks
- Parça Durumu
- Active
- Isolation
- 50dB (min)
- Operating Frequency Max
- 40000MHz
- Çalışma Sıcaklığı
- -40°C~85°C
- Body Length Or Diameter
- 34mm
- Coil Currentdcmax
- 0.08A
- Switching Time
- 10 ms
- Besleme Gerilimi
- 24V~30V
- Insertion Loss
- 0.8dB (max)
- Vswr
- 1.9
- Mounting Feature
- PANEL MOUNT
- Body Breadth
- 12.8 mm
- Input Powermax Cw
- 80W
- Body Height
- 38mm
- Yüzey Montaj
- NO
