Adet bazlı fiyat
- 1+ adet$27.02
- 10+ adet$25.49
- 100+ adet$24.04
- 500+ adet$22.68
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Mating Cycles
- 500
- Mounting Feature
- Bulkhead - Front Side Nut
- Kurşunsuz Kodu
- yes
- Connector Style
- SMA
- Insulation Resistance
- 5GOhm
- Iec Conformance
- NO
- Mil Conformance
- NO
- Fastening Type
- Threaded
- Mating Information
- NO
- Option
- HERMETIC
- Parça Durumu
- Active
- Includes
- 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
- RoHS Durumu
- RoHS Compliant
- Montaj Tipi
- Panel Mount
- Connector Type
- Jack, Female Socket
- Polarity
- Standard
- Filter Feature
- NO
- Reach Svhc
- Unknown
- Cable Group
- RG-174, 316
- Vswr
- 1.4
- Center Contact Plating
- Gold
- Voltage Rated Ac
- 250V
- Material
- Brass
- Center Contact Material
- Beryllium Copper
- Radyasyon Dayanımı
- No
- Body Material
- Stainless Steel
- Gender
- Female
- Shield Termination
- Crimp
- Uzunluk
- 40mm
- Contact Termination
- Solder
- Ambalaj
- Bulk
- Number Of Ports
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -65°C~165°C
- Contact Materials
- Copper
- Empedans
- 50Ohm
- Orientation
- Straight
- Depth
- 8mm
- Frekans
- 12.4GHz
- Din Conformance
- NO
