Adet bazlı fiyat
- 1+ adet$9.42
- 10+ adet$8.89
- 100+ adet$8.39
- 500+ adet$7.91
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Voltage Rated Ac
- 250V
- Insertion Loss
- 0.05 dB
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Radyasyon Dayanımı
- No
- Parça Durumu
- Active
- Contact Termination
- Crimp
- Connector Type
- Plug, Female Socket
- Fabrika Tedarik Süresi
- 6 Weeks
- Total Number Of Contacts
- 1
- JESD-609 Kodu
- e4
- Fastening Type
- Snap-On
- Mil Conformance
- NO
- Yayın Yılı
- 2003
- Center Contact Plating
- Gold
- Contact Style
- COAX
- Cable Group
- RG-174, 179, 316
- Number Of Ports
- 1
- Nominal Gerilim
- 335V
- Gender
- Male
- Montaj
- Cable
- Body Material
- Brass
- Iec Conformance
- NO
- Orientation
- Straight
- Din Conformance
- NO
- Filter Feature
- NO
- Empedans
- 50Ohm
- Insulation Resistance
- 1GOhm
- Frekans
- 4GHz
- Center Contact Material
- Beryllium Copper
- Option
- GENERAL PURPOSE
- Contact Resistance
- 8mOhm
- Reach Svhc
- Unknown
- Uzunluk
- 20.6mm
- RoHS Durumu
- RoHS Compliant
- Montaj Tipi
- Free Hanging (In-Line)
- Kurşunsuz Kodu
- yes
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Copper
- Mating Cycles
- 500
