8PM-11-0004-02-131

Teknik Özellikler

Ambalaj

Bulk

Contact Finish Thickness

10.0μin 0.25μm

Orientation

Straight

Number Of Contacts

4

Contact Finish

Gold

Max Current Rating

3A

Reliability

COMMERCIAL

Uzunluk

10.16mm

ECCN Kodu

EAR99

Seri

8PM

Depth

7.3mm

Sıra Sayısı

1

Contact Resistance

10mOhm

Montaj Tipi

Surface Mount, Right Angle

Connector Type

Piston

Body Breadth

0.096 inch

Contact Pattern

RECTANGULAR

Parça Durumu

Active

Gender

Female

Max Voltage Rating Ac

100V

Pitch

0.100 2.54mm

Min. Çalışma Sıcaklığı

-55°C

Fabrika Tedarik Süresi

10 Weeks

Maks. Çalışma Sıcaklığı

125°C

Rated Current Signal

3A

Yayın Yılı

2012

Reference Standard

UL

Pcb Contact Pattern

RECTANGULAR

Number Of Pcb Rows

1

Nem Hassasiyeti (MSL)

1 (Unlimited)

Montaj

Surface Mount

Number Of Conductors

ONE

Max Voltage Rating Dc

150V

Housing Color

Black

Radyasyon Dayanımı

No

Terminal

Solder

Material

Brass

Durability

50000 Cycles

RoHS Durumu

ROHS3 Compliant

Housing Material

Polychlorinated
