Adet bazlı fiyat
- 1+ adet$0.68
- 10+ adet$0.64
- 100+ adet$0.60
- 500+ adet$0.57
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Total Number Of Contacts
- 2
- Max Voltage Rating Dc
- 150V
- Style
- Board to Board
- Contact Finish Thickness Mating
- 29.5μin 0.75μm
- Montaj
- Surface Mount
- Connector Type
- Socket
- Insulation Height
- 0.096 2.44mm
- Pitch Mating
- 0.100 2.54mm
- Nominal Gerilim
- 150V
- Contact Resistance
- 10mOhm
- Fastening Type
- Push-Pull
- Terminal
- Solder
- Pozisyon Sayısı
- 2
- Housing Color
- Black
- Akım Değeri
- 3A
- Polarization Key
- POLARIZED HOUSING
- Gender
- Female
- Rated Current Signal
- 3A
- Number Of Conductors
- ONE
- Reliability
- COMMERCIAL
- Yayın Yılı
- 2012
- Orientation
- Straight
- Material Flammability Rating
- UL94 V-0
- Insulation Materials
- Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
- RoHS Durumu
- ROHS3 Compliant
- Parça Durumu
- Active
- Montaj Tipi
- Surface Mount, Right Angle
- Yükseklik
- 2.44mm
- Body Breadth
- 0.096 inch
- Contact Finish Post
- Tin
- Max Current Rating
- 3A
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 10 Weeks
- HTS Kodu
- 8536.69.40.40
- Contact Finish Mating
- Gold
- Number Of Pcb Rows
- 1
- Depth
- 6.3mm
- Plating Thickness
- 30μin
- Sıra Sayısı
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
