890-18-006-10-003101

Teknik Özellikler

Pozisyon Sayısı

6

Connector Type

Header

Pcb Contact Pattern

RECTANGULAR

Gender

Male

Iec Conformance

NO

Filter Feature

NO

Uzunluk

15.24mm

Mil Conformance

NO

Mixed Contacts

NO

Din Conformance

NO

Fabrika Tedarik Süresi

10 Weeks

Plating Thickness

9.8μin

Material Flammability Rating

UL94 V-0

Parça Durumu

Active

JESD-609 Kodu

e3

Montaj

Through Hole

Insulation Height

0.100 2.54mm

Nominal Gerilim

150VDC

Option

GENERAL PURPOSE

Contact Finish Thickness Mating

10.0μin 0.25μm

Ul Flammability Code

94V-0

Housing Material

Polyamide

Insulation Materials

Polyamide (PA), Nylon, Glass Filled

Shrouding

Unshrouded

Overall Contact Length

0.553 14.04mm

Fastening Type

Push-Pull

Terminal

Solder

Sıra Sayısı

1

Orientation

Straight

Max Voltage Rating Ac

100V

Style

Board to Board

Contact Materials

Brass

Housing Color

Black

Number Of Pcb Rows

1

Contact Type

Male Pin

Contact Lengthmating

0.335 8.51mm

Contact Finish Post

Tin

Contact Shape

Square

Yayın Yılı

2012

Number Of Positions Loaded

All
