Adet bazlı fiyat
- 1+ adet$8.23
- 10+ adet$7.77
- 100+ adet$7.33
- 500+ adet$6.91
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Total Number Of Contacts
- 54
- Montaj
- Surface Mount
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Solder
- Din Conformance
- NO
- Contact Materials
- Beryllium Copper
- Montaj Tipi
- Surface Mount
- Contact Shape
- Circular
- Insulation Color
- Black
- RoHS Durumu
- ROHS3 Compliant
- Pitch Mating
- 0.050 1.27mm
- Seri
- 853
- Mil Conformance
- NO
- Row Spacing Mating
- 0.050 (1.27mm)
- Fastening Type
- Push-Pull
- Parça Durumu
- Active
- Insulation Materials
- Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
- Iec Conformance
- NO
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2012
- JESD-609 Kodu
- e3
- Option
- GENERAL PURPOSE
- Current Rating Amps
- 1A
- Insulation Height
- 0.203 5.16mm
- Fabrika Tedarik Süresi
- 10 Weeks
- Filter Feature
- NO
- Contact Finish Thickness Mating
- Flash
- Connector Type
- Socket
- Contact Finish Mating
- Gold
- Contact Finish Post
- Tin
- Material Flammability Rating
- UL94 V-0
- Ambalaj
- Bulk
- Çalışma Sıcaklığı
- -55°C~125°C
- Style
- Board to Board
- Ul Flammability Code
- 94V-0
- Contact Type
- Female Socket
- Sıra Sayısı
- 2
- Number Of Positions Loaded
- All
- Pozisyon Sayısı
- 54
- Mixed Contacts
- NO
