833-83-028-10-001101

Teknik Özellikler

Polarization Key

POLARIZED HOUSING

Insulation Height

0.165 4.20mm

Fastening Type

Push-Pull

Seri

833

Contact Length Post

0.125 3.18mm

Body Breadth

0.165 inch

Number Of Conductors

ONE

Style

Board to Board

Contact Shape

Circular

Gender

Female

Depth

4.2mm

Number Of Pcb Rows

2

Yayın Yılı

2012

Montaj

Through Hole

Housing Material

Polymer

Fabrika Tedarik Süresi

10 Weeks

Pcb Contact Pattern

RECTANGULAR

Mating Contact Pitch

0.079 inch

Number Of Positions Loaded

All

Contact Finish Thickness Mating

29.5μin 0.75μm

Durability

500 Cycles

Çalışma Sıcaklığı

-55°C~125°C

Terminal

Solder

Rated Current Signal

3A

RoHS Durumu

ROHS3 Compliant

Radyasyon Dayanımı

No

Contact Type

Female Socket

Sıra Sayısı

2

Reliability

COMMERCIAL

ECCN Kodu

EAR99

Contact Finish Post

Tin

Material Flammability Rating

UL94 V-0

Max Voltage Rating Ac

100V

Uzunluk

28mm

Row Spacing Mating

0.079 (2.00mm)

Nem Hassasiyeti (MSL)

1 (Unlimited)

Contact Finish Mating

Gold

Reference Standard

UL

Pitch Mating

0.079 2.00mm

Connector Type

Socket
