Adet bazlı fiyat
- 1+ adet$1.19
- 10+ adet$1.13
- 100+ adet$1.06
- 500+ adet$1.00
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Insulation Height
- 0.165 4.20mm
- Pozisyon Sayısı
- 10
- Fastening Type
- Push-Pull
- Çalışma Sıcaklığı
- -55°C~125°C
- Mixed Contacts
- NO
- Fabrika Tedarik Süresi
- 10 Weeks
- Additional Feature
- LOW PROFILE
- Current Rating Amps
- 3A
- Number Of Positions Loaded
- All
- Pitch Mating
- 0.100 2.54mm
- Contact Materials
- Beryllium Copper
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Color
- Black
- Terminal
- Solder
- Contact Finish Mating
- Gold
- Kurşunsuz Kodu
- yes
- Sıra Sayısı
- 2
- Contact Finish Post
- Tin
- Mil Conformance
- NO
- Style
- Board to Board
- Row Spacing Mating
- 0.100 (2.54mm)
- JESD-609 Kodu
- e3
- Contact Finish Thickness Mating
- Flash
- Yayın Yılı
- 2010
- Ambalaj
- Bulk
- Contact Length Post
- 0.125 3.18mm
- Iec Conformance
- NO
- Filter Feature
- NO
- Insulation Materials
- Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
- Connector Type
- Socket
- Contact Type
- Female Socket
- Ul Flammability Code
- 94V-0
- Contact Shape
- Circular
- Option
- GENERAL PURPOSE
- Parça Durumu
- Active
- Din Conformance
- NO
- Montaj Tipi
- Through Hole
- Seri
- 803
- Material Flammability Rating
- UL94 V-0
- RoHS Durumu
- ROHS3 Compliant
