Adet bazlı fiyat
- 1+ adet$1.97
- 10+ adet$1.86
- 100+ adet$1.75
- 500+ adet$1.65
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Finish Mating
- Gold
- Contact Finish Thickness Mating
- 29.5μin 0.75μm
- Reliability
- COMMERCIAL
- Insulation Materials
- Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
- Body Length Or Diameter
- 2.9 inch
- Fastening Type
- Push-Pull
- Shrouding
- Unshrouded
- Reference Standard
- UL
- Terminal
- Solder
- Sıra Sayısı
- 1
- Çalışma Sıcaklığı
- -55°C~125°C
- Polarization Key
- POLAR PIN POSITION
- Pitch Mating
- 0.200 5.08mm
- Style
- Board to Board
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- Brass
- Contact Type
- Male Pin
- Pozisyon Sayısı
- 8
- Number Of Pcb Rows
- 1
- Contact Lengthmating
- 0.195 4.95mm
- Pcb Contact Pattern
- RECTANGULAR
- Connector Type
- Header
- Contact Finish Post
- Tin
- Contact Shape
- Circular
- Insulation Color
- Black
- Yayın Yılı
- 2012
- Number Of Positions Loaded
- All
- Number Of Conductors
- ONE
- Fabrika Tedarik Süresi
- 10 Weeks
- Material Flammability Rating
- UL94 V-0
- Plating Thickness
- 30μin
- Mating Contact Pitch
- 0.2 inch
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Montaj
- Through Hole
- Current Rating Amps
- 3A
- Insulation Height
- 0.100 2.54mm
- Contact Length Post
- 0.126 3.20mm
- Montaj Tipi
- Through Hole, Right Angle
