Adet bazlı fiyat
- 1+ adet$0.86
- 10+ adet$0.81
- 100+ adet$0.77
- 500+ adet$0.72
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Mixed Contacts
- NO
- Option
- GENERAL PURPOSE
- Yayın Yılı
- 2012
- Connector Type
- Socket
- Pitch
- 2.54mm
- Length Overall
- 0.165 4.19mm
- Additional Feature
- LOW PROFILE
- Parça Durumu
- Active
- Sıra Sayısı
- 1
- Contact Materials
- Beryllium Copper
- Mil Conformance
- NO
- Seri
- 714
- Fabrika Tedarik Süresi
- 10 Weeks
- Gender
- Female
- Rated Current Signal
- 3A
- Contact Finish
- Gold
- Board Thickness
- 0.039 ~ 0.102 1.00mm ~ 2.60mm
- Tail Type
- No Tail
- Ul Flammability Code
- 94V-0
- Flange Diameter
- 0.072 (1.83mm)
- Pcb Contact Pattern
- RECTANGULAR
- Reliability
- COMMERCIAL
- Number Of Pcb Rows
- 1
- Durability
- 500 Cycles
- Ambalaj
- Strip
- Contact Finish Thickness
- Flash
- JESD-609 Kodu
- e3
- Insertion Force
- 2.00N
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Pattern
- RECTANGULAR
- Renk
- Black
- Iec Conformance
- NO
- Çalışma Sıcaklığı
- -55°C~125°C
- Socket Depth
- 0.146 3.71mm
- Terminal
- Solder
- Kılıf / Paket
- SIP
- RoHS Durumu
- ROHS3 Compliant
- Number Of Contacts
- 7
- Montaj
- Through Hole
- Reference Standard
- UL
