Adet bazlı fiyat
- 1+ adet$5.03
- 10+ adet$4.75
- 100+ adet$4.48
- 500+ adet$4.22
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- JESD-609 Kodu
- e3
- Contact Pattern
- RECTANGULAR
- Contact Materials
- Beryllium Copper
- Terminal Adımı
- 2.54mm
- Mating Contact Pitch
- 0.1 inch
- Insulation Resistance
- 10000000000Ohm
- Contact Finish Thickness
- 30.0μin 0.76μm
- Length Overall
- 0.290 7.37mm
- Insertion Force
- 2.00N
- Contact Finish
- Gold
- Seri
- 712
- Uzunluk
- 7.366mm
- Insulator Color
- BLACK
- Contact Gender
- FEMALE
- Dielectric Withstanding Voltage
- 1400VAC V
- Ul Flammability Code
- 94V-0
- Tail Diameter
- 0.020 (0.51mm)
- Ambalaj
- Strip
- Connector Type
- BOARD CONNECTOR
- ECCN Kodu
- EAR99
- Option
- GENERAL PURPOSE
- Number Of Conductors
- ONE
- Reliability
- COMMERCIAL
- Total Number Of Contacts
- 49
- Reference Standard
- UL
- Accepts Pin Diameter
- 0.016 ~ 0.022 (0.41mm ~ 0.56mm)
- Tail Type
- Standard Tail
- Contact Resistance
- 10mOhm
- Montaj Tipi
- BOARD
- Iec Conformance
- NO
- Terminal
- Solder
- Bodyshell Style
- SOCKET
- Flange Diameter
- 0.072 (1.83mm)
- RoHS Durumu
- ROHS3 Compliant
- Mounting Option1
- LOCKING
- Fabrika Tedarik Süresi
- 10 Weeks
- HTS Kodu
- 8536.69.40.40
- Mil Conformance
- NO
- Body Depth
- 0.169 inch
- Insulation Materials
- GLASS FILLED POLYCYCLOHEXYLENE TEREPHTHALLATE
