Adet bazlı fiyat
- 1+ adet$2.07
- 10+ adet$1.95
- 100+ adet$1.84
- 500+ adet$1.73
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fabrika Tedarik Süresi
- 10 Weeks
- Depth
- 18.09mm
- HTS Kodu
- 8536.69.40.40
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Rated Dc
- 150V
- Termination Post Length
- 0.122 3.10mm
- Lead Length
- 3.0988mm
- Housing Material
- Polyphenylene Sulfide (PPS)
- JESD-609 Kodu
- e3
- Contact Finish Mating
- Tin
- Montaj
- Through Hole
- Contact Material Mating
- Phosphor Bronze
- Akım Değeri
- 1A
- Pitch Post
- 0.100 2.54mm
- Radyasyon Dayanımı
- No
- Number Of Contacts
- 28
- Özellikler
- Closed Frame
- ECCN Kodu
- EAR99
- Parça Durumu
- Active
- Insulation Resistance
- 1GOhm
- RoHS Durumu
- ROHS3 Compliant
- Uzunluk
- 18.09mm
- Tip
- PLCC
- Seri
- 540
- Montaj Tipi
- Through Hole
- Contact Material Post
- Phosphor Bronze
- Voltage Rated Ac
- 100V
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2008
- Number Of Positions Or Pins Grid
- 28 (4 x 7)
- Gender
- Female
- Material Flammability Rating
- UL94 V-0
- Contact Materials
- Bronze
- Pitch Mating
- 0.050 1.27mm
- Terminal
- Solder
- Contact Resistance
- 20mOhm
- Ambalaj
- Bulk
- Min. Çalışma Sıcaklığı
- -55°C
- Insulation Materials
- Polyphenylene
- Orientation
- Straight
