350-10-156-01-666101

Teknik Özellikler

Contact Type

Male Pin

Pozisyon Sayısı

56

Contact Finish Thickness Post

10.0μin 0.25μm

Contact Lengthmating

0.141 3.60mm

JESD-609 Kodu

e4

Contact Finish Thickness Mating

10.0μin 0.25μm

Reference Standard

UL

Material Flammability Rating

UL94 V-0

RoHS Durumu

ROHS3 Compliant

Number Of Pcb Rows

1

Number Of Positions Loaded

All

Contact Length Post

0.110 2.79mm

Connector Type

Header

Fastening Type

Push-Pull

Sıra Sayısı

1

Pcb Contact Pattern

RECTANGULAR

Terminal Adımı

2.54mm

Insulation Color

Black

Pitch Mating

0.100 2.54mm

Terminal

Press-Fit, Solder

Ambalaj

Bulk

Yayın Yılı

2012

Number Of Conductors

ONE

Shrouding

Unshrouded

Overall Contact Length

0.390 9.90mm

Current Rating Amps

3A

Body Length Or Diameter

5.6 inch

Durability

500 Cycles

Nominal Gerilim

150VDC

Style

Board to Board

Contact Materials

Brass

Parça Durumu

Active

Insulation Materials

Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled

Çalışma Sıcaklığı

-55°C~125°C

Insulation Height

0.116 2.95mm

Contact Shape

Circular

Seri

350

Montaj

Through Hole

Contact Finish Mating

Gold

Nem Hassasiyeti (MSL)

1 (Unlimited)
