310-87-105-01-609101

Teknik Özellikler

Ambalaj

Bulk

Nem Hassasiyeti (MSL)

1 (Unlimited)

Polarization Key

POLARIZED HOUSING

Terminal

Solder

Contact Length Post

0.125 3.18mm

Contact Type

Female Socket

Number Of Pcb Rows

1

Insulation Color

Black

Current Rating Amps

3A

Number Of Conductors

ONE

Insulation Height

0.165 4.20mm

Contact Finish Post

Tin

Pcb Contact Pattern

RECTANGULAR

Fabrika Tedarik Süresi

10 Weeks

Connector Type

Socket

Mating Contact Pitch

0.2 inch

Number Of Positions Loaded

All

Insulation Materials

Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled

Montaj

Through Hole

Parça Durumu

Active

Montaj Tipi

Through Hole

Sıra Sayısı

1

Pozisyon Sayısı

5

Gender

Female

Reliability

COMMERCIAL

JESD-609 Kodu

e3

Çalışma Sıcaklığı

-55°C~125°C

Style

Board to Board

Filter Feature

NO

Contact Materials

Beryllium Copper

Mil Conformance

NO

Iec Conformance

NO

Contact Shape

Circular

Mixed Contacts

NO

Pitch Mating

0.200 5.08mm

Yayın Yılı

2012

Kurşunsuz Kodu

yes

Material Flammability Rating

UL94 V-0

Fastening Type

Push-Pull

Contact Finish Mating

Gold
