Adet bazlı fiyat
- 1+ adet$6.07
- 10+ adet$5.72
- 100+ adet$5.40
- 500+ adet$5.09
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Finish Thickness Mating
- Flash
- Montaj
- Horizontal, Through Hole
- JESD-609 Kodu
- e3
- Voltage Rated Ac
- 100V
- Yayın Yılı
- 2012
- Özellikler
- Closed Frame
- Flammability Rating
- UL94 V-0
- Tip
- DIP, 0.6 (15.24mm) Row Spacing
- ECCN Kodu
- EAR99
- Number Of Contacts
- 20
- Montaj Tipi
- Through Hole, Right Angle, Horizontal
- Housing Material
- Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
- Pitch Mating
- 0.100 2.54mm
- Akım Değeri
- 1A
- Lead Length
- 3.2512mm
- Contact Material Post
- Brass
- Contact Resistance
- 10mOhm
- Ambalaj
- Bulk
- RoHS Durumu
- ROHS3 Compliant
- Contact Finish Mating
- Gold
- Contact Material Mating
- Beryllium Copper
- Pcb Contact Pattern
- RECTANGULAR
- Additional Feature
- 94V-0
- Row Spacing
- 15.24 mm
- Insulation Materials
- Polychlorinated
- Pitch Post
- 0.100 2.54mm
- Contact Finish Post
- Tin
- Seri
- 299
- Insulation Resistance
- 10GOhm
- Contact Materials
- Copper
- Number Of Positions Or Pins Grid
- 20 (2 x 10)
- Depth
- 17.7mm
- Uzunluk
- 25.3mm
- Orientation
- Right Angle
- Voltage Rated Dc
- 150V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mating Contact Pitch
- 0.1 inch
- Material Flammability Rating
- UL94 V-0
- Kurşunsuz Kodu
- yes
- Sıra Sayısı
- 2
