Adet bazlı fiyat
- 1+ adet$6.29
- 10+ adet$5.94
- 100+ adet$5.60
- 500+ adet$5.28
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Depth
- 8.14mm
- Seri
- 299
- Number Of Positions Or Pins Grid
- 14 (2 x 7)
- Contact Materials
- Copper
- Insulation Resistance
- 10GOhm
- Insulation Materials
- Polychlorinated
- Pitch Post
- 0.100 2.54mm
- Contact Finish Post
- Tin
- Row Spacing
- 7.62 mm
- Additional Feature
- 94V-0
- Contact Material Mating
- Beryllium Copper
- Termination Post Length
- 0.128 3.24mm
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -55°C~125°C
- Fabrika Tedarik Süresi
- 10 Weeks
- Terminal
- Solder
- HTS Kodu
- 8536.69.40.40
- Sıra Sayısı
- 2
- Kurşunsuz Kodu
- yes
- Material Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Rated Dc
- 150V
- Uzunluk
- 17.7mm
- Orientation
- Right Angle
- ECCN Kodu
- EAR99
- Tip
- DIP, 0.3 (7.62mm) Row Spacing
- Flammability Rating
- UL94 V-0
- Özellikler
- Closed Frame
- JESD-609 Kodu
- e3
- Yayın Yılı
- 2012
- Voltage Rated Ac
- 100V
- Montaj
- Horizontal, Through Hole
- Contact Finish Thickness Mating
- 29.5μin 0.75μm
- Ambalaj
- Bulk
- Contact Finish Mating
- Gold
- RoHS Durumu
- ROHS3 Compliant
- Contact Material Post
- Brass
- Contact Resistance
- 10mOhm
- Lead Length
- 3.2512mm
- Housing Material
- Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
