Adet bazlı fiyat
- 1+ adet$17.65
- 10+ adet$16.66
- 100+ adet$15.71
- 500+ adet$14.82
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Adapter Type
- Plug to Jack
- Center Contact Material
- Beryllium Copper
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Insulation Materials
- Polytetrafluoroethylene
- Vswr
- 1.25
- Coupling Type
- THREADED-THREADED
- Mil Conformance
- NO
- Montaj Tipi
- Free Hanging (In-Line)
- Body Material
- Brass
- Style
- Straight
- Iec Conformance
- NO
- Convert To Adapter End
- SMA Jack, Female Socket
- Yayın Yılı
- 2002
- Reach Svhc
- No SVHC
- HTS Kodu
- 8536.69.80.00
- Kılıf / Paket
- SMA
- Polarity
- Normal
- Contact Materials
- Brass, Copper
- Frekans
- 4GHz
- RoHS Durumu
- ROHS3 Compliant
- JESD-609 Kodu
- e4
- Adapter Series
- SMA to SMB
- Mating Cycles
- 500
- Conversion Type
- Between Series
- Din Conformance
- NO
- Connector Type
- Coaxial, SMA, SMB
- Ambalaj
- Bulk
- Depth
- 6.4mm
- Empedans
- 50Ohm
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 2 Weeks
- Gender Type B
- Female
- Additional Feature
- STANDARDS: MIL-C-39012; IEC 169-15
- Convert From Adapter End
- SMB Plug, Female Socket
- Montaj
- Free Hanging
- Fastening Type
- Snap-On, Threaded
- Center Contact Plating
- Gold
- Option
- GENERAL PURPOSE
- Uzunluk
- 19.2mm
- Kurşunsuz Kodu
- yes
