Adet bazlı fiyat
- 1+ adet$20.87
- 10+ adet$19.69
- 100+ adet$18.57
- 500+ adet$17.52
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Depth
- 12.7mm
- Connector Type
- Coaxial, SMA
- Ambalaj
- Bulk
- Conversion Type
- Same Series
- Mating Cycles
- 500
- Adapter Series
- SMA to SMA
- JESD-609 Kodu
- e4
- RoHS Durumu
- ROHS3 Compliant
- Mounting Feature
- Flange
- Frekans
- 18GHz
- Contact Materials
- Copper
- Dielectric Withstanding Voltage
- 1000VAC V
- Kılıf / Paket
- SMA
- Polarity
- Normal
- HTS Kodu
- 8536.69.80.00
- Reach Svhc
- No SVHC
- Yayın Yılı
- 2002
- Convert To Adapter End
- SMA Jack, Female Socket
- Body Material
- Brass
- Style
- Straight
- Montaj Tipi
- Panel Mount
- Vswr
- 1.25
- Insulation Materials
- Polytetrafluoroethylene
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Center Contact Material
- Beryllium Copper
- Adapter Type
- Jack to Jack
- Çalışma Sıcaklığı
- -65°C~165°C
- Filter Feature
- NO
- Center Gender
- Female to Female
- Nem Hassasiyeti (MSL)
- Not Applicable
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Uzunluk
- 22.2mm
- Option
- GENERAL PURPOSE
- Center Contact Plating
- Gold
- Fastening Type
- Threaded, Threaded
- Radyasyon Dayanımı
- No
- Montaj
- Flanges, Panel
- Additional Feature
- STANDARDS: MIL-C-39012; IEC 169-15
- Convert From Adapter End
- SMA Jack, Female Socket
