Adet bazlı fiyat
- 1+ adet$1.10
- 10+ adet$1.04
- 100+ adet$0.98
- 500+ adet$0.92
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Depth
- 21.59mm
- Insulation
- Non-Insulated
- Body Plating
- Tin
- Terminal Style
- Single Stud Hole
- Tab Thickness
- 0.130 3.30mm
- HTS Kodu
- 8536.90.40.00
- Studtab Size
- 3/8 Stud
- Diameter Barrel Od
- 0.670 (17.02mm)
- Gender
- Female
- Seri
- Pan-Lug®
- Length Overall
- 2.520 64.00mm
- Montaj Tipi
- Free Hanging (In-Line)
- Montaj
- Free Hanging
- Ambalaj
- Bulk
- Terminal Type
- Rectangular Tongue
- Radyasyon Dayanımı
- No
- Diameter Ring Id
- 0.410 (10.41mm)
- Wire Gauge Min
- 1 AWG
- Renk
- Black
- Wire Gauge Max
- 0 AWG
- Contact Finish
- Electro-Tin
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Diameter Barrel Id
- 0.450 (11.43mm)
- Terminal
- Crimp, Barrel
- Weight
- 335.658382g
- Width Outer Edges
- 0.850 21.59mm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Yayın Yılı
- 2004
- Uzunluk
- 64.008mm
- Contact Materials
- Copper
- Fabrika Tedarik Süresi
- 4 Weeks
- Terminal And Terminal Block Type
- RING TERMINAL
- ECCN Kodu
- EAR99
- RoHS Durumu
- ROHS3 Compliant
- Wire Gauge
- 1/0 AWG
