Adet bazlı fiyat
- 1+ adet$34.34
- 10+ adet$32.39
- 100+ adet$30.56
- 500+ adet$28.83
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- ECCN Kodu
- EAR99
- Ambalaj
- Bulk
- Parça Durumu
- Active
- Terminal Style
- Two Stud Holes
- Terminal
- Screw
- Fabrika Tedarik Süresi
- 4 Weeks
- Contact Materials
- Aluminum
- RoHS Durumu
- ROHS3 Compliant
- Tab Thickness
- 0.250 6.35mm
- Wire Gauge
- 1/0-14 AWG
- Nem Hassasiyeti (MSL)
- Not Applicable
- Wire Gauge Max
- 14 AWG
- Yayın Yılı
- 2011
- Uzunluk
- 73.914mm
- Özellikler
- 3 Cable Entries, With Screw
- Length Overall
- 2.910 73.91mm
- Wire Cross Section
- 53.51 mm2
- Montaj
- Free Hanging
- Montaj Tipi
- Free Hanging (In-Line)
- Seri
- LAM3B
- Terminal Type
- Lug, Grounding
- Terminal And Terminal Block Type
- WIRE TERMINAL
- Radyasyon Dayanımı
- No
- Contact Finish
- Tin
- Wire Gauge Min
- 0 AWG
- Terminal Gender
- FEMALE
- Studtab Size
- 3/8 Stud
- HTS Kodu
- 8536.90.40.00
- Width Outer Edges
- 2.000 50.80mm
- Body Material
- Aluminium
- Insulation
- Non-Insulated
