Adet bazlı fiyat
- 1+ adet$0.96
- 10+ adet$0.90
- 100+ adet$0.85
- 500+ adet$0.80
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Seri
- DiscoGrip™
- Wire Gauge Max
- 12 AWG
- Radyasyon Dayanımı
- No
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Cross Section
- 6 mm2
- Wire Gauge
- 10-12 AWG
- Wire Gauge Min
- 10 AWG
- Tab Thickness
- 0.032 0.81mm
- Montaj Tipi
- Free Hanging (In-Line)
- Body Material
- Copper
- HTS Kodu
- 8536.90.40.00
- Insulation Diameter
- 0.140 ~ 0.220 (3.56mm ~ 5.59mm)
- RoHS Durumu
- ROHS3 Compliant
- Gender
- Female
- Nem Hassasiyeti (MSL)
- Not Applicable
- Parça Durumu
- Active
- Genişlik
- 8.89mm
- Depth
- 8.9mm
- Montaj
- Free Hanging
- Contact Plating
- Tin
- Terminal
- Crimp
- Width Tab
- 0.250 6.35mm
- Ambalaj
- Bulk
- Terminal And Terminal Block Type
- PUSH-ON TERMINAL
- Insulation Materials
- Nylon
- Insulation
- Fully Insulated
- Length Overall
- 0.960 24.38mm
- Yayın Yılı
- 2001
- Uzunluk
- 24.384mm
- Renk
- Yellow
- ECCN Kodu
- EAR99
- Terminal Type
- Standard
- Contact Materials
- Brass
