Adet bazlı fiyat
- 1+ adet$0.39
- 10+ adet$0.37
- 100+ adet$0.35
- 500+ adet$0.33
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Seri
- Disco™ ReelSmart™
- Parça Durumu
- Active
- Wire Gauge
- 14-16 AWG
- Insulation Diameter
- 0.160 (4.06mm)
- Yayın Yılı
- 2011
- Ambalaj
- Tape & Reel (TR)
- Nem Hassasiyeti (MSL)
- Not Applicable
- Wire Gauge Min
- 14 AWG
- Length Overall
- 0.780 19.81mm
- Contact Materials
- Brass
- Özellikler
- Butted Seam
- Width Tab
- 0.187 4.75mm
- Renk
- Blue
- Terminal And Terminal Block Type
- PUSH-ON TERMINAL
- Insulation
- Fully Insulated
- RoHS Durumu
- ROHS3 Compliant
- Contact Plating
- Tin
- Terminal Type
- Standard
- Wire Gauge Max
- 16 AWG
- Uzunluk
- 19.812mm
- HTS Kodu
- 8536.90.40.00
- Depth
- 7.4mm
- Gender
- Female
- Fabrika Tedarik Süresi
- 4 Weeks
- Montaj
- Free Hanging
- Montaj Tipi
- Free Hanging (In-Line)
- Tab Thickness
- 0.032 0.81mm
- Radyasyon Dayanımı
- No
- Terminal
- Crimp
- ECCN Kodu
- EAR99
