Teknik Özellikler
- Min Supply Voltage Dc
- 12V
- RoHS Durumu
- RoHS Compliant
- Additional Feature
- IP 67, SHORT-CIRCUIT PROTECTION, REVERSE POLARITY PROTECTION
- Housing Material
- Polybutylene
- Algılama Mesafesi
- 0.079 ~ 0.984 (2mm ~ 25mm) ADJ
- Connection Method
- Cable
- Yükseklik
- 13mm
- Montaj
- Screw
- Seri
- EX-10
- Besleme Gerilimi
- 12V~24V
- Reach Svhc
- Yes
- Output Configuration
- PNP - Open Collector
- Fabrika Tedarik Süresi
- 8 Weeks
- Parça Durumu
- Active
- Measurement Rangemax
- 25 mm
- Max Voltage Rating Dc
- 24V
- Kablo Uzunluğu
- 78.74 2m
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Turn On Delay Time
- 500 μs
- REACH Uyumluluk Kodu
- unknown
- Measurement Rangemin
- 2 mm
- Yayın Yılı
- 2001
- Sensing Method
- Reflective, Diffuse
- Sensorstransducers Type
- LINEAR POSITION SENSOR,PHOTOELECTRIC,DIFFUSE
- Ingress Protection
- IP67
- Çalışma Sıcaklığı
- -25°C~55°C
- Genişlik
- 3.5mm
- Output Current
- 50mA
- Max Supply Voltage Dc
- 24V
- Body Length Or Diameter
- 10mm
- Repeatability
- 0.05
- Light Source
- Red LED
