Teknik Özellikler
- Çalışma Sıcaklığı
- -25°C~55°C
- Body Length Or Diameter
- 10mm
- Repeatability
- 0.05
- Light Source
- Red LED
- Max Supply Voltage Dc
- 24V
- Output Current
- 50mA
- Turn On Delay Time
- 500 μs
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kablo Uzunluğu
- 78.74 2m
- Measurement Rangemax
- 500 mm
- Parça Durumu
- Active
- Body Breadth
- 4.5 mm
- Ingress Protection
- IP67
- Sensing Method
- Through-Beam
- Yayın Yılı
- 2008
- Measurement Rangemin
- 500 mm
- REACH Uyumluluk Kodu
- unknown
- Besleme Gerilimi
- 12V~24V
- Seri
- EX-10
- Montaj
- Screw
- Fabrika Tedarik Süresi
- 8 Weeks
- Body Height
- 19mm
- Output Configuration
- NPN - Open Collector/Dark-ON
- Housing Material
- Polybutylene
- Additional Feature
- IP 67, SHORT-CIRCUIT PROTECTION, REVERSE POLARITY PROTECTION
- RoHS Durumu
- RoHS Compliant
- Min Supply Voltage Dc
- 12V
- Connection Method
- Cable
- Algılama Mesafesi
- 19.685 (500mm)
