EX-11EA

Teknik Özellikler

Yayın Yılı

2003

REACH Uyumluluk Kodu

unknown

Body Breadth

4.5 mm

Ingress Protection

IP67

Sensing Method

Through-Beam

Parça Durumu

Active

Turn On Delay Time

500 μs

Nem Hassasiyeti (MSL)

1 (Unlimited)

Kablo Uzunluğu

78.74 2m

Output Current

50mA

Max Supply Voltage Dc

24V

Body Length Or Diameter

10mm

Light Source

Red LED

Repeatability

0.05

Çalışma Sıcaklığı

-25°C~55°C

Connection Method

Cable

Algılama Mesafesi

5.9 (15cm)

Min Supply Voltage Dc

12V

Housing Material

Polybutylene

Additional Feature

IP 67, SHORT-CIRCUIT PROTECTION, REVERSE POLARITY PROTECTION

RoHS Durumu

RoHS Compliant

Output Configuration

NPN - Open Collector/Light-ON

Body Height

19mm

Fabrika Tedarik Süresi

8 Weeks

Besleme Gerilimi

12V~24V

Seri

EX-10

Montaj

Screw
