Teknik Özellikler
- Contact Bounce Timemax
- 10ms
- Contact Plating
- Gold, Silver
- Uzunluk
- 6.4mm
- Contact Resistance
- 500mOhm
- Actuator Type
- Rectangular Button
- Voltage Rated Dc
- 12V
- HTS Kodu
- 8536.50.90.40
- Akım Değeri
- 50mA
- ECCN Kodu
- EAR99
- Illumination
- Non-Illuminated
- Contact Dc Max Rating R Load
- .05A@12VDC
- Terminal
- Gull Wing
- Yayın Yılı
- 2012
- Contact Currentdcmax
- 0.05A
- Mechanical Life
- 100,000 Cycles
- Contact Rating Voltage
- 0.05A @ 12VDC
- Circuit
- SPST-NO
- Kurşunsuz
- Lead Free
- Kurşunsuz Kodu
- yes
- Actuator Length
- 1mm
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -20°C~70°C
- Max Voltage Rating Dc
- 12V
- Illumination Type
- Illuminated, Non-Illuminated
- Actuator Orientation
- Side Actuated
- Number Of Switches
- 1
- Packing Method
- BOX; TAPE AND REEL
- Throw Configuration
- SPST
- Montaj Tipi
- Surface Mount, Right Angle
- Outline
- 6.40mm x 3.50mm
- Reach Svhc
- Unknown
- Terminal Stili
- Gull Wing
- Switch Type
- KEYPAD SWITCH
- Orientation
- Straight
- Montaj
- Surface Mount
- Contact Current Rating
- 50mA
- Electricallife
- 100000 cycles
- Fabrika Tedarik Süresi
- 6 Weeks
- Body Breadth
- 3.5 mm
- Switch Travel
- 0.30mm
