Teknik Özellikler
- Akım Değeri
- 20mA
- HTS Kodu
- 8536.50.90.40
- Voltage Rated Dc
- 15V
- Actuator Type
- Standard
- Contact Resistance
- 50mOhm
- Uzunluk
- 7.5mm
- Contact Bounce Timemax
- 8ms
- Contact Plating
- Silver
- Genişlik
- 6.2mm
- Actuatorcolor
- BLACK
- Circuit
- SPST-NO
- Mechanical Life
- 100,000 Cycles
- Contact Rating Voltage
- 0.02A @ 15VDC
- Yayın Yılı
- 2010
- Terminal
- PC Pins
- Contact Function
- OFF-(ON)
- Illumination
- Non-Illuminated
- ECCN Kodu
- EAR99
- Çalışma Sıcaklığı
- -20°C~70°C
- Parça Durumu
- Last Time Buy
- Actuator Length
- 8.35mm
- Kurşunsuz Kodu
- yes
- Kurşunsuz
- Lead Free
- Throw Configuration
- SPST
- Actuator Orientation
- Side Actuated
- Number Of Switches
- 1
- Packing Method
- BAG; BOX
- Yükseklik
- 8.35mm
- Illumination Type
- Illuminated, Non-Illuminated
- Max Voltage Rating Dc
- 15V
- Terminal Stili
- PC Pin
- Switch Type
- KEYPAD SWITCH
- Reach Svhc
- Unknown
- Outline
- 7.50mm x 7.10mm
- Montaj Tipi
- Through Hole, Right Angle
- Switch Travel
- 0.25mm
- Fabrika Tedarik Süresi
- 15 Weeks
- Electricallife
- 100000 cycles
- Contact Current Rating
- 20mA
- Montaj
- Through Hole
