Adet bazlı fiyat
- 1+ adet$0.09
- 500+ adet$0.06
- 1000+ adet$0.05
- 2000+ adet$0.05
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Yükseklik
- 7mm
- Illumination Type
- Illuminated, Non-Illuminated
- Max Voltage Rating Dc
- 15V
- Actuator Orientation
- Top Actuated
- Number Of Switches
- 1
- Packing Method
- BAG; BOX
- Throw Configuration
- SPST
- Kurşunsuz
- Lead Free
- Parça Durumu
- Last Time Buy
- Çalışma Sıcaklığı
- -20°C~70°C
- Kurşunsuz Kodu
- yes
- Actuator Length
- 3.1mm
- Contact Dc Max Rating R Load
- .02A@15VDC
- Illumination
- Non-Illuminated
- ECCN Kodu
- EAR99
- Mechanical Life
- 50,000 Cycles
- Contact Rating Voltage
- 0.02A @ 15VDC
- Circuit
- SPST-NO
- Terminal
- PC Pin
- Contact Currentdcmax
- 0.02A
- Yayın Yılı
- 2011
- Contact Resistance
- 50mOhm
- Uzunluk
- 6mm
- Actuator Type
- Standard
- Contact Bounce Timemax
- 8ms
- HTS Kodu
- 8536.50.90.40
- Akım Değeri
- 20mA
- Voltage Rated Dc
- 15V
- Radyasyon Dayanımı
- No
- Switch Function
- Off-Mom
- Ambalaj
- Bulk
- Max Current Rating
- 20mA
- Depth
- 7.8mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- RoHS Compliant
- Seri
- EVQPA
- Operating Force
- 260gf
- Actuator Height Off Pcb Vertical
- 7.00mm
- JESD-609 Kodu
- e4
- Orientation
- Straight
