Teknik Özellikler
- Radyasyon Dayanımı
- No
- Switch Function
- Off-Mom
- Max Voltage Rating Dc
- 12V
- Ambalaj
- Tape & Reel (TR)
- Packing Method
- BOX; TAPE AND REEL
- Number Of Switches
- 1
- Actuator Orientation
- Side Actuated
- Throw Configuration
- SPST
- Depth
- 3.55mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Current Rating
- 50mA
- RoHS Durumu
- RoHS Compliant
- Seri
- EVQP3
- Kurşunsuz
- Lead Free
- Operating Force
- 220gf
- Parça Durumu
- Obsolete
- Çalışma Sıcaklığı
- -20°C~70°C
- Kurşunsuz Kodu
- yes
- Actuator Length
- 650μm
- Contact Dc Max Rating R Load
- .05A@12VDC
- Illumination
- Non-Illuminated
- JESD-609 Kodu
- e4
- ECCN Kodu
- EAR99
- Orientation
- Right Angle
- Switch Travel
- 0.20mm
- Contact Rating Voltage
- 0.05A @ 12VDC
- Body Breadth
- 2.9 mm
- Mechanical Life
- 100,000 Cycles
- Circuit
- SPST-NO
- Body Height
- 1.35mm
- Terminal
- Gull Wing
- Montaj
- Surface Mount
- Electricallife
- 100000 cycles
- Yayın Yılı
- 2012
- Contact Currentdcmax
- 0.05A
- Contact Resistance
- 500mOhm
- Uzunluk
- 4.7mm
- Actuator Type
- Rectangular Button
- Montaj Tipi
- Surface Mount, Right Angle
- Outline
- 4.70mm x 2.90mm
