Adet bazlı fiyat
- 1+ adet$0.40
- 10+ adet$0.38
- 100+ adet$0.36
- 500+ adet$0.34
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Function
- OFF-(ON)
- Contact Dc Max Rating R Load
- .02A@15VDC
- Illumination
- Non-Illuminated
- ECCN Kodu
- EAR99
- Circuit
- SPST-NO
- Actuatorcolor
- NATURAL
- Contact Rating Voltage
- 0.02A @ 15VDC
- Mechanical Life
- 1,000,000 Cycles
- Contact Currentdcmax
- 0.02A
- Yayın Yılı
- 2010
- Terminal
- J-Bend
- Actuator Type
- Rectangular Button
- Contact Resistance
- 100mOhm
- Uzunluk
- 3.5mm
- Contact Bounce Timemax
- 10ms
- Akım Değeri
- 20mA
- Contact Timing
- SNAP ACTION
- HTS Kodu
- 8536.50.90.40
- Voltage Rated Dc
- 15V
- Illumination Type
- Illuminated, Non-Illuminated
- Yükseklik
- 2.1mm
- Max Voltage Rating Dc
- 15V
- Throw Configuration
- SPST
- Packing Method
- BOX; TAPE AND REEL
- Actuator Orientation
- Top Actuated
- Number Of Switches
- 1
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- -40°C~85°C
- Parça Durumu
- Active
- Actuator Length
- 450μm
- Kurşunsuz Kodu
- yes
- JESD-609 Kodu
- e4
- Orientation
- Straight
- Switch Travel
- 0.25mm
- Fabrika Tedarik Süresi
- 6 Weeks
- Electricallife
- 1e+06 cycles
- Contact Current Rating
- 20mA
- Montaj
- Surface Mount
- Outline
- 4.70mm x 3.50mm
- Montaj Tipi
- Surface Mount
