Adet bazlı fiyat
- 1+ adet$0.57
- 10+ adet$0.54
- 100+ adet$0.51
- 500+ adet$0.48
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Actuatorcolor
- GRAY
- Circuit
- SPST-NO
- Mechanical Life
- 500,000 Cycles
- Contact Rating Voltage
- 0.02A @ 15VDC
- Yayın Yılı
- 2010
- Terminal
- J-Bend
- Contact Function
- OFF-(ON)
- Illumination
- Non-Illuminated
- ECCN Kodu
- EAR99
- Akım Değeri
- 20mA
- HTS Kodu
- 8536.50.90.40
- Voltage Rated Dc
- 15V
- Additional Feature
- TAPE AND REEL PACKAGING
- Actuator Type
- Standard
- Contact Resistance
- 100mOhm
- Uzunluk
- 3.5mm
- Contact Bounce Timemax
- 10ms
- Contact Plating
- Gold, Silver
- Genişlik
- 4.7mm
- Throw Configuration
- SPST
- Actuator Orientation
- Top Actuated
- Number Of Switches
- 1
- Packing Method
- BOX; TAPE AND REEL
- Yükseklik
- 2.5mm
- Illumination Type
- Illuminated, Non-Illuminated
- Max Voltage Rating Dc
- 15V
- Çalışma Sıcaklığı
- -40°C~85°C
- Parça Durumu
- Active
- Actuator Length
- 850μm
- Kurşunsuz Kodu
- yes
- Kurşunsuz
- Lead Free
- Switch Travel
- 0.70mm
- Fabrika Tedarik Süresi
- 6 Weeks
- Electricallife
- 500000 cycles
- Contact Current Rating
- 20mA
- Montaj
- Surface Mount
- JESD-609 Kodu
- e4
- Orientation
- Straight
- Pozisyon Sayısı
- 2
- Terminal Stili
- J Lead
