Adet bazlı fiyat
- 1+ adet$0.02
- 500+ adet$0.01
- 1000+ adet$0.01
- 2000+ adet$0.01
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Genişlik
- 63.5mm
- Contact Bounce Timemax
- 8ms
- Contact Plating
- Silver
- Kılıf / Paket
- Radial
- Actuator Type
- Standard
- Uzunluk
- 6mm
- Contact Resistance
- 50mOhm
- Voltage Rated Dc
- 15V
- Akım Değeri
- 20mA
- HTS Kodu
- 8536.50.90.40
- ECCN Kodu
- EAR99
- Illumination
- Non-Illuminated
- Contact Dc Max Rating R Load
- .02A@15VDC
- Contact Currentdcmax
- 0.02A
- Yayın Yılı
- 2011
- Terminal
- PC Pin
- Circuit
- SPST-NO
- Contact Rating Voltage
- 0.02A @ 15VDC
- Mechanical Life
- 100,000 Cycles
- Kurşunsuz
- Lead Free
- Actuator Length
- 900μm
- Kurşunsuz Kodu
- yes
- Çalışma Sıcaklığı
- -20°C~70°C
- Parça Durumu
- Last Time Buy
- Max Voltage Rating Dc
- 15V
- Illumination Type
- Illuminated, Non-Illuminated
- Yükseklik
- 9.525mm
- Throw Configuration
- SPST
- Packing Method
- BOX; TAPE AND REEL
- Actuator Orientation
- Top Actuated
- Number Of Switches
- 1
- Outline
- 6.00mm x 6.00mm
- Montaj Tipi
- Through Hole
- Switch Type
- KEYPAD SWITCH
- Terminal Stili
- PC Pin
- Reach Svhc
- Unknown
- Orientation
- Straight
- JESD-609 Kodu
- e4
- Electricallife
- 100000 cycles
- Fabrika Tedarik Süresi
- 12 Weeks
