Teknik Özellikler
- Capacitor Type
- ALUMINUM ELECTROLYTIC CAPACITOR
- Ripple Current
- 455mA
- Lead Spacing
- 0.098 2.50mm
- Lead Diameter
- 500 μm
- Radyasyon Dayanımı
- No
- Fabrika Tedarik Süresi
- 14 Weeks
- Parça Durumu
- Active
- Yükseklik
- 11.2mm
- Tan Delta
- 0.16
- Lifetime Temp
- 5000 Hrs @ 105°C
- Esr Equivalent Series Resistance
- 130mOhm
- Montaj Tipi
- Through Hole
- Ripple Current Low Frequency
- 318.5mA @ 120Hz
- Nem Hassasiyeti (MSL)
- Not Applicable
- Gerilim
- 16V
- Ripple Current High Frequency
- 455mA @ 100kHz
- Çap
- 6.3mm
- Terminal Shape
- WIRE
- Kurşunsuz Kodu
- yes
- Seri
- FR
- Kapasitans
- 220μF
- Kılıf / Paket
- Radial, Can
- Maks. Oturma Yüksekliği
- 0.500 12.70mm
- Applications
- General Purpose
- Leadbase Style
- Straight
- Empedans
- 130mOhm
- RoHS Durumu
- RoHS Compliant
- Life Hours
- 5000 hours
- Tolerans
- ±20%
- Polarization
- Polar
- Contact Plating
- Tin
- Terminal Sayısı
- 2
- Lead Pitch
- 2.5mm
- Leakage Current
- 35.2μA
- Voltage Rated Dc
- 16V
- Boyut / Ölçü
- 0.248Dia 6.30mm
- Kurşunsuz
- Lead Free
- ECCN Kodu
- EAR99
- JESD-609 Kodu
- e3
- Reach Svhc
- No SVHC
