Adet bazlı fiyat
- 1+ adet$0.26
- 10+ adet$0.25
- 100+ adet$0.24
- 500+ adet$0.22
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Lead Spacing
- 0.098 2.50mm
- Ripple Current
- 405mA
- Capacitor Type
- ALUMINUM ELECTROLYTIC CAPACITOR
- Lead Diameter
- 500 μm
- Radyasyon Dayanımı
- No
- Fabrika Tedarik Süresi
- 14 Weeks
- Tan Delta
- 0.1
- Yükseklik
- 11.2mm
- Parça Durumu
- Active
- Lifetime Temp
- 2000 Hrs @ 105°C
- Esr Equivalent Series Resistance
- 140mOhm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Ripple Current Low Frequency
- 283.5mA @ 120Hz
- Montaj Tipi
- Through Hole
- Gerilim
- 50V
- Ripple Current High Frequency
- 405mA @ 100kHz
- Kapasitans
- 56μF
- Çap
- 6.3mm
- Terminal Shape
- WIRE
- Seri
- FM
- Kurşunsuz Kodu
- yes
- Kılıf / Paket
- Radial, Can
- Maks. Oturma Yüksekliği
- 0.500 12.70mm
- Ripple Current Ac
- 405mA
- Applications
- General Purpose
- RoHS Durumu
- RoHS Compliant
- Empedans
- 140mOhm
- Life Hours
- 2000 hours
- Polarization
- Polar
- Tolerans
- ±20%
- Lead Pitch
- 2.5mm
- Terminal Kaplaması
- Tin (Sn)
- Terminal Sayısı
- 2
- Dissipation Factor
- 0.1 %
- Voltage Rated Dc
- 50V
- Boyut / Ölçü
- 0.248Dia 6.30mm
- Kurşunsuz
- Lead Free
- ECCN Kodu
- EAR99
- Reach Svhc
- No SVHC
- JESD-609 Kodu
- e3
