Adet bazlı fiyat
- 1+ adet$1.34
- 10+ adet$1.27
- 100+ adet$1.19
- 500+ adet$1.13
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Lead Diameter
- 600 μm
- Lead Spacing
- 0.197 5.00mm
- Ripple Current
- 807mA
- Capacitor Type
- ALUMINUM ELECTROLYTIC CAPACITOR
- Lifetime Temp
- 5000 Hrs @ 105°C
- Yükseklik
- 25mm
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 14 Weeks
- Radyasyon Dayanımı
- No
- Nem Hassasiyeti (MSL)
- Not Applicable
- Ripple Current Low Frequency
- 524.6mA @ 120Hz
- Montaj Tipi
- Through Hole
- Esr Equivalent Series Resistance
- 110mOhm
- Gerilim
- 100V
- Ripple Current High Frequency
- 807mA @ 100kHz
- Kılıf / Paket
- Radial, Can
- Kapasitans
- 150μF
- Terminal Shape
- WIRE
- Kurşunsuz Kodu
- yes
- Seri
- FC
- Ratings
- AEC-Q200
- Çap
- 12.5mm
- Maks. Oturma Yüksekliği
- 0.984 25.00mm
- Empedans
- 110mOhm
- RoHS Durumu
- RoHS Compliant
- Applications
- Automotive
- Multilayer
- No
- Polarization
- Polar
- Tolerans
- ±20%
- Life Hours
- 5000 hours
- Contact Plating
- Tin
- Lead Pitch
- 5mm
- Terminal Sayısı
- 2
- Voltage Rated Dc
- 100V
- Boyut / Ölçü
- 0.492Dia 12.50mm
- Leakage Current
- 3μA
- Dissipation Factor
- 0.07 %
- Reach Svhc
- No SVHC
- JESD-609 Kodu
- e3
- Kurşunsuz
- Lead Free
