EEH-ZA1V680XP

Teknik Özellikler

Terminal Sayısı

2

Applications

Automotive

Tan Delta

0.12

Nem Hassasiyeti (MSL)

1 (Unlimited)

Yayın Yılı

2013

Maks. Oturma Yüksekliği

0.315 8.00mm

Esr Equivalent Series Resistance

35mOhm

Leakage Current

0.0238mA

Surface Mount Land Size

0.260Lx0.260W 6.60mmx6.60mm

Montaj Tipi

Surface Mount

Ripple Current High Frequency

2A @ 100kHz

RoHS Durumu

ROHS3 Compliant

Lifetime Temp

10000 Hrs @ 105°C

ECCN Kodu

EAR99

Seri

ZA

Tolerans

±20%

Dielectric Material

ALUMINUM

Uzunluk

7.8mm

Ambalaj

Tape & Reel (TR)

Boyut / Ölçü

0.248Dia 6.30mm

Additional Feature

ESR IS MEASURED AT 100 KHZ

Rated Dc Voltage Urdc

35V

Çalışma Sıcaklığı

-55°C~105°C

Ratings

AEC-Q200

Tip

Hybrid

Polarity

POLARIZED

Kılıf / Paket

Radial, Can - SMD

Packing Method

TR, EMBOSSED, 15 INCH

Fabrika Tedarik Süresi

12 Weeks

Parça Durumu

Active

Ripple Current Low Frequency

300mA @ 100Hz

HTS Kodu

8532.24.0020

Terminal Shape

FLAT

Kapasitans

68μF

Genişlik

6.6mm

Nominal Gerilim

35V

Size Code

2626
